Mechanics of Materials
The MS12 metal material fatigue testing experimental device is a key equipment used in material mechanics experiments to study the failure behavior of materials under alternating loads.
MS12 focuses on "cumulative damage". Reveal why metal components suddenly fracture after thousands of cycles under stress far below the yield limit. The core goal is to draw S-N curves (stress life curves), determine the fatigue limit of materials, and observe the typical characteristics of fatigue fracture surfaces.
Share:
Added to cart successfully
Experimental feature
1.Drawing of S-N curve (stress life curve)
2.Determination of fatigue limit
3.Symmetrical cyclic bending fatigue test
4.The effect of stress concentration on fatigue life
5.Research on Surface State and Size Effect (Advanced Function)
Product Attributes
|
Product Model |
MS12 |
Product Name |
Rotating fatigue testing experimental device |
|
Main Materials |
Aluminum, carbon steel |
Dimensions | ≤1000×400×1000mm |
|
Product Weight |
20kg |
Operating Environment |
Room temperature, relative humidity ≤ 85% |
|
Input Power Supply |
None | ||
|
Required Modules |
None |
Optional Modules |
None |
