Fundamentals of Heat Transfer
This product is designed to be used together with the Heat Transfer Basic Experimental Platform to carry out experiments related to the one-dimensional steady-state heat conduction law in Fourier’s Law of Heat Conduction from the course Heat Transfer.
The apparatus mainly consists of a brass disk with a central heating rod. With the support of the experimental platform, it can be used to measure the thermal conductivity of the brass disk and to verify the heat conduction characteristics of cylindrical materials under radial heat transfer conditions.
Share:
Added to cart successfully
Experimental Functions
1.Used to study and verify the principle of one-dimensional steady-state heat conduction, and analyze the radial heat transfer process and temperature distribution in cylindrical materials.
2.Measures the steady-state temperature distribution along the cylindrical wall (radial heat flow).
3.Measures the thermal conductivity of disk-shaped materials.
Product Attributes
|
Product Model |
TH102 |
Product Name |
Radial Heat Conduction Experimental Apparatus |
|
Main Materials |
H62 Brass, Black Nylon |
Dimensions |
340 × 210 × 190 mm |
|
Product Weight |
4.8kg |
Operating Environment |
Room temperature, Relative humidity ≤ 85% |
|
Input Power Supply |
None |
||
|
Required Modules |
Constant-temperature water bath |
Optional Modules |
None |
